INTEGRATION GUIDE FOR THE TOPCON KR-1W

Serial Cables must be purchased from Topcon prior to integration

TOPCON KR1W CONFIGURATION

1. Go into the settings menu:

2. COM Settings:

3. Print Int:

4. Network:

Ref/KRT Data Output (STD2):

CRYSTAL MACHINE UTILITY CONFIGURATION

Set up the Crystal PM Machine Utility using the following instructions: Crystal PM Machine Integration Utility Setup

CRYSTAL CONFIGURATION

Add the Machine:

1. In Crystal, go to the Records tab

2. In Records, navigate to EHR Settings à Import Machines à Select an open Machine Slot

3. A window will open with a list a of machines, click on “Browse for available machines” at the bottom

4. Choose the machine labeled “Topcon KR1W”

5. Browse to the .txt output location (C:\Program Files (x86)\CrystalPM\mach\mach1\mach1.txt)

6. Click open, then leave the Records tab in Crystal and then come back to it (Click on Tasks tab then click back onto records tab.)

Create the button in records:

1. In Records, navigate to EHR Settings à Edit Medical Record Templates

2. At the bottom of the Edit Fields Window click on “Add New Field”

3. Make the field type to be a button

4. Assign the fields in your template to the corresponding fields from the .txt file below:

5. Add field to template and Save Changes

MACHINE BUTTON MAPPING

ID	DATA	Example
1	File Location	C:\Users\Paul\Desktop\machines\topcon\kr1\mach1.txt
2	Time	3:32 PM
3	OD Sphere	-5
4	OD Cyl
5	OD Axis
6	OS Sphere	-4.5
7	OS Cyl	-0.75
8	OS Axis	21
9	R1 OD K mm	7.84
10	R1 OD K diopter	43
11	R1 OD K Axis	152
12	R2 OD K mm	7.78
13	R2 OD K diopter	43.5
13	R2 OD K Axis	62
15	Ave OD K mm	7.81
16	Ave OD K Cyl	-0.25
17	Ave OD K Axis	152
18	R1 OS K mm	7.84
19	R1 OS K diopter	43
20	R1 OS K Axis	152
21	R2 OS K mm	7.78
22	R2 OS K diopter	43.5
23	R2 OS K Axis	62
24	Ave OS K mm	7.81
25	Ave OS K Cyl	-0.25
26	Ave OS K Axis	152
27	PD	59
28	VD	12
